• Designed to place plastic or metal caps on a wide range of containers – enclosures
• Includes one set of change of parts (star wheel, outer guide, cap delivery and chuck)
• Acasi magnetic clutch capping head model MJ90 (Magnetic with Jaws), visual torque setting for ease of adjustment, manufactured in 304 stainless steel
• Pick and place mechanism in stainless steel. Cap is delivered to the chuck, then the chuck comes down holding the cap (This prevents cross-threading)
• Fully adjustable from 7” to 14” high containers. (Special configurations available on request)
• Maximum bottle diameter with 12 pocket star wheel: 4.25”
• Maximum bottle diameter with 6 pocket star wheel: 8.00”
• Automatic start and stop with presence or absence of containers
• 12 or 6 pocket center star wheel for container handling (Depends on the size of the container)
• Jamming clutches with electric signal for shutdown on product jamming (This prevents major damage to parts and minimizes possible spills)
• 2 Hp AC motor with frequency drive speed control
• Stainless steel electric enclosure.
• Heavy duty 304 Stainless steel welded frame
• Stainless steel enclosure with polycarbonate windows and safety switches
• All shafts from ¼ to 2.5” are manufactured in 304 stainless steel
• Gear driven transmission machine to avoid timing loss
• Complete height adjustment with bottle setting guide for quick changeovers
• Tool-less changeovers for star wheels and most change parts

Cap chute features:

• All contact parts in stainless steel
• Designed and tested for each cap to avoid jamming
• Includes cap demand sensor to start and stop the cap feeder
• Quick change over, since parts are pin guided so no tweaking is required

Vibratory cap feeder features:

• Aluminum casting with polyurethane liner to minimizes cap marking-scratching
• 24” diameter feeding disc – ramp assembly.
• Bad caps rejected mechanically, minimum air usage.
• Cap by demand controlled by photoelectric sensor.
• Bowl tooled for one model cap
• Adjustable vibration and speed control
• Heavy duty extra heavy base for better vibration central
• Sorter mounted on machine, no need for independent height adjustment
• Includes filter regulator.
• Flow controls on all air hoses.

• Designed to place and form metal caps on a wide range of containers – enclosures.
• Price includes one set of change of parts (star wheel, outer guide and cap delivery)
• ACASI ROPP capping head model VA90, manufactured in 304 stainless steel and hardened forming discs
• Bottle will pick up cap and the container will be indexed into position
• Fully adjustable from 7” to 14” high containers (special configurations available on request)
• Maximum bottle diameter with 12 pocket star wheel: 4.25”
• Maximum bottle diameter with 6 pocket star wheel: 8.00”
• Center CAM manufactured in special cam rated plastic material
• Automatic start and stop with presence or absence of containers
• 12 or 6 pocket center star wheel for container handling (Depends on the size of the container)
• Jamming clutches with electric signal for shutdown on product jamming (This prevents major damage to parts and minimizes possible spills)
• 2 Hp AC motor with frequency drive speed control
• Stainless steel electric enclosure
• Heavy duty 304 stainless steel welded frame
• Stainless steel enclosure with polycarbonate windows and safety switches
• All shafts from ¼ to 2.5” are manufactured in 304 stainless steel
• Gear driven transmission machine to avoid timing loss
• Complete height adjustment with bottle setting guide for quick changeovers
• Tool less changeovers for star wheels and most change parts

Cap chute features:

• All contact parts in stainless steel
• Designed and tested for each cap to avoid jamming.
• Includes cap demand sensor to start and stop the cap feeder
• Quick change over, since parts are pin guided so no tweaking is required

Vibratory cap feeder features:

• Aluminum casting with polyurethane liner to minimizes cap marking-scratching
• 24” diameter feeding disc – ramp assembly
• Bad caps rejected mechanically, minimum air usage
• Cap by demand controlled by photoelectric sensor
• Bowl tooled for one model cap
• Adjustable vibration and speed control
• Heavy duty extra heavy base for better vibration central
• Sorter mounted on machine, no need for independent height adjustment
• Includes filter regulator
• Flow controls on all air hoses

• Designed to place plastic or metal caps on a wide range of containers – enclosures
• Price includes one set of change parts (star wheel, outer guide, cap delivery and chuck)
• ACASI magnetic clutch capping head model MJ90 (Magnetic with Jaws), visual torque setting for ease of adjustment, manufactured in 304 stainless steel
• Pick and place mechanism in stainless steel. Cap is delivered to the chuck, and then the chuck comes down holding the cap (This prevents cross- threading)
• Fully adjustable from 7” to 14” high containers. (Special configurations available on request)
• Maximum bottle diameter with 12 pocket star wheel: 4.25”
• Maximum bottle diameter with 6 pocket star wheel: 8.00”
• Center CAM manufactured in special cam rated plastic material
• Automatic start and stop with presence or absence of containers
• 12 or 6 pocket center star wheel for container handling (Depends on the size of the container)
• Jamming clutches with electric signal for shutdown on product jamming (This prevents major damage to parts and minimizes possible spills)
• 2 Hp AC motor with frequency drive speed control
• Stainless steel electric enclosure
• Heavy duty 304 stainless steel welded frame
• Stainless steel enclosure with polycarbonate windows and safety switches
• All shafts from ¼ to 2.5” manufactured in 304 stainless steel
• Gear driven transmission machine to avoid timing loss
• Complete height adjustment with bottle setting guide for quick changeovers
• Tool-less changeovers for star wheels and most change parts

Cap chute features:

• All contact parts in stainless steel
• Designed and tested for each cap to avoid jamming
• Includes cap demand sensor to start and stop the cap feeder
• Quick change over, since parts are pin guided so no tweaking is required.
• Cap feeder and orienting features:
• Construction in stainless steel
• 18” wide belt
• Belt spacing designed for your application, can accommodate caps from 8 mm to 110 mm in diameter
• Cap by demand controlled by photoelectric sensor
• Air shutoff valve controlled by photoelectric sensor
• Includes filter regulator
• Knob adjustments of cap delivery system from 8mm to 110mm
• Inclination range from 0 to 5 degrees
• Complete height adjustment by structure 1 inch bolts and/or cap delivery system
• 10 cubic foot cap hopper
• System drive provided by DC gear motor
• Speed control by potentiometer
